Hangzhou Wencheng Chemical Biotech Co., Ltd.

Dipropylene glycol diacrylate
Dipropylene glycol diacrylate
Dipropylene glycol diacrylate

Dipropylene glycol diacrylate

Contact Us
  • Category

    Acrylate series

  • Describe

    Dipropylene glycol diacrylate (DPGDA) is a commonly used bifunctional acrylate reactive monomer, which is widely used in ultraviolet (UV) curing systems such as coatings, inks, adhesives, electronic packaging and 3D printing materials.

  • Cas No.

    57472-68-1

  • Purity

    mixture

  • Synonym(s)

    DPGDA

Physical and chemical properties

  • 1. Chemical Identity
    • Chemical Name: Dipropylene glycol diacrylate
    • IUPAC Name: Oxybis(methyl-2,1-ethanediyl) diacrylate
    • Synonyms: DPGDA, Oxybis(propanol) diacrylate
    • CAS Number: 57472-68-1
    • EC Number: 260-754-3
    • Molecular Formula: C12​H18​O5​
    • Molecular Weight: 242.27 g/mol
  • 2. Physical Properties
    • Appearance: Clear, colorless liquid.
    • Odor: Mild, characteristic, acrylic/ester-like.
    • Melting Point: <-60 °C (<-76 °F)
    • Boiling Point: >200 °C (>392 °F) at 1013 hPa
    • Density: 1.05 g/cm³ at 20 °C
    • Solubility:
    • In Water: 6.7 g/L at 20 °C (Slightly soluble)
    • In Organic Solvents: Soluble in many common organic solvents.
    • Vapor Pressure: <0.1 hPa at 20 °C
    • Viscosity: 6 - 15 mPa·s at 25 °C
  • 3. Chemical Properties and Stability
    • Stability: Stable under recommended storage conditions. Typically supplied with a polymerization inhibitor (e.g., MEHQ).
    • Incompatibilities: Incompatible with strong oxidizing agents, strong bases, strong acids, reducing agents, peroxides, and free-radical initiators.
    • Hazardous Polymerization: May occur if not properly inhibited or if exposed to high temperatures, direct sunlight, UV radiation, or contaminants. Polymerization is a highly exothermic reaction.
    • Hazardous Decomposition Products: Combustion may produce toxic fumes of carbon monoxide (CO) and carbon dioxide (CO2​).
  • 4. Other Key Data
    • Flash Point: >110 °C (>230 °F) - Closed cup
    • Refractive Index (n20/D): ~1.450


MSDS

Dipropylene glycol diacrylate--MSDS     Download


Certificates Of Analysis

Dipropylene glycol diacrylate--COA      Download


Application

1. Ultraviolet (UV) coatings, wood coatings such as solid wood floor UV topcoat, furniture high gloss varnish, cabinet wear-resistant coating; plastic product coatings such as automotive interior UV coatings, mobile phone shell hardening coatings, home appliance decorative paints; metal decorative coatings such as metal sign anti-light rubbing coatings, beverage can outer wall protective layers.

2. Printing inks, water-based UV inks for food soft packaging, pharmaceutical aluminum foil inks; electronic product inks such as circuit board (PCB) marking inks, touch screen inks; special inks such as anti-counterfeiting label fluorescent inks, low-temperature curing silk screen inks.

3. Adhesives and sealants, industrial adhesives such as automotive LED light positioning glue, electronic component packaging glue, sensor packaging glue, chip packaging glue; other glues such as flexible screen optical transparent glue (OCA), furniture traceless repair UV glue.

4. 3D printing materials, dental braces resin, jewelry model resin, industrial design rapid prototyping resin.

5. Electronic materials, electronic protective coatings such as circuit board moisture-proof paint, circuit board anti-salt spray paint, circuit board dust-proof paint, flexible circuit (FPC) insulation coating, optical materials such as optical fiber secondary coating, AR/VR lens anti-reflective coating.

6. Personal care products, nail products such as nail gel, wash-free sealing glue; medical device coatings such as catheter hydrophilic coating, dental resin materials.

7. Other industrial applications include inkjet printing varnish, flame retardant clothing UV curing finishing agent, optical glue (OCR), display screen full bonding glue, etc.

Safety Information

  • This information is a summary based on the Globally Harmonized System of Classification and Labelling of Chemicals (GHS).
    • 1. GHS Classification
      • Skin Irritation (Category 2)
      • Serious Eye Damage (Category 1)
      • Skin Sensitization (Category 1)
      • Specific Target Organ Toxicity — Single Exposure (Category 3), Respiratory System
      • Hazardous to the Aquatic Environment, Chronic Hazard (Category 3)
    • 2. GHS Label Elements
      • Pictograms:
        • Corrosion (GHS05)
        • Exclamation Mark (GHS07)
      • Signal Word: Danger
      • Hazard Statements (H-Statements):
        • H315: Causes skin irritation.
        • H317: May cause an allergic skin reaction.
        • H318: Causes serious eye damage.
        • H335: May cause respiratory irritation.
        • H412: Harmful to aquatic life with long lasting effects.
      • Precautionary Statements (P-Statements):
      • Prevention:
        • P261: Avoid breathing dust/fume/gas/mist/vapors/spray.
        • P272: Contaminated work clothing should not be allowed out of the workplace.
        • P280: Wear protective gloves, protective clothing, eye protection, and face protection.
      • Response:
        • P302 + P352: IF ON SKIN: Wash with plenty of soap and water.
        • P305 + P351 + P338 + P310: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. Immediately call a POISON CENTER or doctor/physician.
        • P333 + P313: If skin irritation or rash occurs: Get medical advice/attention.
        • P362 + P364: Take off contaminated clothing and wash it before reuse.
      • Storage:
        • P403 + P233: Store in a well-ventilated place. Keep container tightly closed.
      • Disposal:
        • P501: Dispose of contents/container to an approved hazardous waste disposal plant.
    • 3. Summary of Primary Hazards
      • Health Hazards: Causes serious, potentially irreversible, eye damage. Causes skin irritation and is a known skin sensitizer, meaning repeated contact can lead to the development of an allergic skin reaction (contact dermatitis). Vapors or mists may cause respiratory irritation.
      • Environmental Hazards: Harmful to aquatic life with long-lasting effects. Release into the environment should be avoided.
      • Reactivity Hazards: The product is a reactive monomer that can undergo hazardous polymerization if not properly stabilized and handled. Keep away from heat, sunlight, and contamination.
